GM LS Rectangle Port Carbureted Dual Plane Aluminum Intake Manifold - Polished
HomeStore

GM LS Rectangle Port Carbureted Dual Plane Aluminum Intake Manifold - Polished

GM LS Rectangle Port Carbureted Dual Plane Aluminum Intake Manifold - Polished

$430.23
GM LS Rectangle Port Carbureted Dual Plane Aluminum Intake Manifold - Polished—
$430.23

The Story

TSP's dual-plane high-performance intake manifold for the GM LS Gen IV Rectangular Port is ideal for street performance carbureted applications. Its design improves throttle response, as well as power and torque over a wide rpm range - idle to 5,500. It is cast from lightweight aluminum and features a low profile for ideal hood clearance.

Compatible with:
CHEVROLET SMALL BLOCK V8 GEN. IV (LS BASED)
• 6.2 L / 376 in3

Specifications:
Basic Operating RPM Range: 1,500-6,500 RPM
Carburetor Flange Style: 4150 Square Bore
Carburetor Quantity: 1
Color: Polished
Deck Height: Standard
EGR Port: No
Front Maximum Height: 5.070 in.
Fuel System Type: Carbureted
Gasket Or Seal Included: Yes
Grade Type: Performance
Intake Port Shape: Rectangle
Material: Aluminum
Mounting Hole Quantity: 10
Rear Maximum Height: 6.140 in.
Single Or Dual Plane Type: Dual Plane
GM LS Rectangle Port Carbureted Dual Plane Aluminum Intake Manifold - Polished - Image 2

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

GM LS Rectangle Port Carbureted Dual Plane Aluminum Intake Manifold - Polished - Image 3

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Description

TSP's dual-plane high-performance intake manifold for the GM LS Gen IV Rectangular Port is ideal for street performance carbureted applications. Its design improves throttle response, as well as power and torque over a wide rpm range - idle to 5,500. It is cast from lightweight aluminum and features a low profile for ideal hood clearance.

Compatible with:
CHEVROLET SMALL BLOCK V8 GEN. IV (LS BASED)
• 6.2 L / 376 in3

Specifications:
Basic Operating RPM Range: 1,500-6,500 RPM
Carburetor Flange Style: 4150 Square Bore
Carburetor Quantity: 1
Color: Polished
Deck Height: Standard
EGR Port: No
Front Maximum Height: 5.070 in.
Fuel System Type: Carbureted
Gasket Or Seal Included: Yes
Grade Type: Performance
Intake Port Shape: Rectangle
Material: Aluminum
Mounting Hole Quantity: 10
Rear Maximum Height: 6.140 in.
Single Or Dual Plane Type: Dual Plane
