Pontiac V8 Dual Plane Aluminum Intake Manifold - Black

TSP's dual-plane high-performance intake manifold for the Pontiac V8 is ideal for street performance applications. With a design that improves throttle response, as well as power and torque over a wide rpm range - idle to 5,500. It is cast from lightweight aluminum and features a low profile for ideal hood clearance.

Compatible with:
PONTIAC V8
• 5.3 L / 326 in3
• 5.7 L / 350 in3
• 6.4 L / 389 in3
• 6.6 L / 400 in3
• 7.5 L / 455 in3

NOTE: No provision for factory style choke.

Specifications:
Basic Operating RPM Range: 1,500-6,500 RPM
Carburetor Flange Style: Spread Bore
Carburetor Quantity: 1
Center Maximum Height: 7.450 in.
CNC Ported: No
Color: Black
Deck Height: Standard
EGR: No
Front Maximum Height: 6.880 in.
Fuel System Type: Carbureted
Gasket Or Seal Included: No
Grade Type: Performance
Intake Port Shape: Rectangle
Material: Aluminum
Rear Maximum Height: 8.000 in.
Single Or Dual Plane Type: Dual Plane
