Chrome Volkswagen Beetle Bosch Style 55 Amp Alternator

This 55 A Cylindrical alternator is built for Volkswagen air-cooled applications that need reliable charging capacity with a clean chrome finish. It provides the electrical output needed to support upgraded ignition systems, electric cooling fans, fuel pumps, lighting, and additional accessories.

High Output Charging Performance
With a 55 A output rating, this alternator delivers the charging capacity needed for vehicles running added electrical demand. Strong output helps maintain consistent system voltage in street, cruise, and stop-and-go driving conditions.

Consistent Voltage & Electrical Stability
The internal charging design helps reduce voltage drop that can affect ignition performance, fuel delivery, lighting, and sensitive electronic components under load.

Durable Internal Construction
Built with quality internal components, this alternator is designed to handle heat, vibration, and sustained electrical demand commonly found in street and performance applications.

V-belt Pulley Configuration
Equipped with a v-belt pulley setup, this unit should be matched to the belt system and mounting layout listed in the specifications.

Direct-Fit Installation
The Cylindrical case and strap support a straightforward installation when paired with the correct brackets, wiring, and pulley alignment.

Fitment

COMPATIBLE WITH
VOLKSWAGEN AIR-COOLED FLAT 4
• 1.1 L / 1,131 cc in3
• 1.2 L / 1,192 cc in3
• 1.3 L / 1,285 cc in3
• 1.5 L / 1,457 cc in3
• 1.5 L / 1,493 cc in3
• 1.6 L / 1,584 cc in3
• 1.7 L / 1,679 cc in3
• 1.8 L / 1,795 cc in3
• 1.9 L / 1,915 cc in3
• 2.0 L / 1,970 cc in3
• 2.1 L / 2,109 cc in3

NOTE: Designed to fit 1.6 L 1975-1979 Beetles and Vanagons but will work with most 40 HP or larger engine.

Specifications:
AC Service Tap: No
Amperage Rating: 55 A
Brushless: No
Case Circumference: 14.140 in.
Case Color: Silver
Case Material: Aluminum
External Fan Included: No
External Regulator Included: No
Family: Cylindrical
Fan Type: External
Finish: Chrome
Ground Type: Case ground
Mounting Type: Strap
One Wire Capable: Yes
Plug Clock Rear View Main Mounting Ear at 6 O Clock: 12 o'clock
Plug Type: 1-pin
Pulley Belt Type: V-belt
Pulley Included: No
Regulator Type: Internal
Rotation Direction: Clockwise
Terminal Quantity: 2
Voltage: 12 VDC
