Chevy SB/BB V8 HEI Distributor with Super Cap

TSP’s HEI Distributor has everything you need, all under one cap. With a high-quality aluminum housing and hardened steel dual bushing construction, it is built to last. It features fully adjustable mechanical and vacuum advances, meaning precision is a breeze. It has a high-output module, high-spark 65,000 volt coil, solid brass terminals, and an easy one-wire hookup.

This distributor is designed for a 12 volt electrical system with an alternator. It is not compatible with a generator and cannot be used with a ballast resistor.

Compatible with:
CHEVROLET BIG BLOCK V8 GEN. II (MARK IV)
• 6.5 L / 396 in3
• 6.6 L / 402 in3
• 7.4 L / 454 in3

CHEVROLET SMALL BLOCK V8 GEN. I
• 4.3 L / 262 in3
• 4.3 L / 265 in3
• 4.4 L / 267 in3
• 4.6 L / 283 in3
• 4.9 L / 302 in3
• 5.0 L / 305 in3
• 5.0 L / 307 in3
• 5.4 L / 327 in3
• 5.7 L / 350 in3
• 6.6 L / 400 in3

NOTE: Will not fit tall deck blocks.
Will not fit if using a governor.
Distributor gear is most compatible with cast iron hydraulic or solid flat tappet camshafts; consult cam manufacturer for recommended gear material.

Specifications:
Advance Adjustable: Yes
Advance Type: Centrifugal (Mechanical) And Vacuum
Cap Color: Available in Black, Blue, Red, Clear
Terminal Gender: Super Cap
Centrifugal Advance Adjustment Hardware Included: No
Coil Wire Included: No
Distributor Cap Included: Yes
Gear Material: Hardened Steel
Grade Type: Performance
Housing Material: Aluminum
Ignition Box Required: No
Ignition Coil Included: Yes
Ignition Coil Output: 65000 V
Ignition Rotor Included: Yes
Marine Approved: No
Mechanical Tachometer Drive: No
Rotor Rotation: Clockwise
Shaft Material: Steel
Slip Collar: No
Terminal Gender: Male
Terminal Material: Brass
Terminal Quantity: 8
Trigger Type: Magnetic
Vacuum Advance Adjustment Tool Included: Yes
Coil Type: Internal
